MODEL: HXM558-G |
|||
|
TECHNICAL PARAMETER TABLE |
|||
|
INJECTION UNIT |
SCREW DIAMETER قطر ماردون |
mm |
100 |
|
SCREW L/D RATIO نسبت D/L ماردون |
L/D |
19 |
|
|
INJECTION CAPACITY IN THEORY حجم تزریق |
cm3 |
3691 |
|
|
INJECTION WEIGHT(PS) وزن تزریق بر مبناي پلی استایرن |
g |
3360 |
|
|
oz |
118.5 |
||
|
INJECTION PRESSURE فشار تزریق |
MPa |
147 |
|
|
INJECTION RATE نرخ تزریق |
g/s |
685 |
|
|
PLASTICIZING CAPACITY |
g/s |
100 |
|
|
SCREW SPEED سرعت ماردون |
rpm |
150 |
|
|
CLAMPING UNIT واحد گیره |
CLAMPING FORCE نیروي گیره |
KN |
5580 |
|
MOVING MOULD-PLATE STROKE کورس بازشو گیره |
mm |
870 |
|
|
MAX. MOULD HEIGHT بیشترین ارتفاع قالب |
mm |
830 |
|
|
MIN. MOULD HEIGHT کمترین ارتفاع قالب |
mm |
330 |
|
|
SPACE BWTWEEN TIE-BARS (W×H) فاصله بین تایبارها |
mm |
870*840 |
|
|
HYDRAULIC EJECTOR FORCE نیروي پران |
mm |
181 |
|
|
HYDRAULIC EJECTOR STROKE کورس پران |
KN |
230 |
|
|
EJECTOR NUMBER تعداد میل پران |
n |
17 |
|
|
OTHERS سایر |
PUMP PRESSURE حداکثر فشار پمپ |
MPa |
17.5 |
|
MOTOR /DRIVING POWER توان موتور پمپ |
KW |
40+40 |
|
|
HEATING CAPACITY توان المنت ها |
KW |
30 |
|
|
MACHINE DIMENSION (L×W×H) ابعاد دستگاه |
m |
8.35*2.19*2.4 |
|
|
MACHINE WEIGHT وزن دستگاه |
t |
20.5 |
|
|
OIL TANK CAPACITY ظرفیت مخزن روغن |
L |
1150 |
|
HXM558-G: HXM optimized edition for crate/painting bucket
Optimized feature:
1.Enlarged motor & pump system, optimized hydraulic system to satisify high-performance with quicker cycle. Like crate(less than 2kg) cycle time20S;
paiting bucket(780-800g) cycle time 20S.
2.Specially designed screw and barrel with structure of quicker plasticization, shorten the material charging cycle.
Optional with bi-metal screw and barrel to compatible with recycling material for crate.
3.Optional with automatic facilities to improve the production efficieny.
